DOD-STD-35-71A(MI)

14 January 1983

KEYWORD CODE INDEX (KCI)

CHAR

CODE

CHARACTERISTIC NAME

DIELECTRIC WITHSTANDING VOLTAGE AT REDUCED

BAROMETRIC PRESSURE (CONT)

NO EVIDENCE OF FLASHOVER, MECHANICAL

DAMAGE, ARCING, OR INSULATION BREAKDOWN. (CONT)

4894

MAXIMUM LEAKAGE (MILLIAMPERES)

SWITCHING POINT (SELECT ONE)

2540

CONFORM TO CALIBRATION REQUIREMENTS.

2542

MAXIMUM CHANGE (DEGREES CELSIUS)

2544

MAXIMUM CHANGE (DEGREES FAHRENHEIT)

TEST METHODS (SELECT ONE)

4884

PER BASE DOCUMENT EXCEPT

6300

PER MIL�STD�202, METHOD 301.

*ALTITUDE PER METHOD 105 OF MIL�STD�202

4886

*TEST CONDITION (LETTER)

*TEST VOLTAGE (SELECT ONE)

4885

(VOLTS, DC)
