DOD-STD-35-138(MI)
5 January 1979
CHAR
CODE
STANDARD
PARAGRAPH
1744 THE TEST CIRCUIT SHALL NOT EMPLOY CURRENT LEVELS THAT
CAN ADVERSELY AFFECT SWITCHING CAPABILITIES.
1746 THE LOAD SHALL BE 1746.
1782 COINCIDENCE OF OPERATING AND RELEASE POINTS (SIMULTANEITY).
THE REQUIREMENT(S) SHALL BE IN ACCORDANCE WITH THE BASE
DOCUMENT, EXCEPT 1782.
1784 COINCIDENCE OF OPERATING AND RELEASE POINTS (SIMULTANEITY).
THE REQUIREMENT(S) SHALL BE AS FOLLOWS:
1786 ALL CONTACTS SHALL TRANSFER WITHIN 1786 MILLISECOND(S).
3200 ALL CONTACTS SHALL TRANSFER WITHIN 3200 INCH OF ACTUATOR
TRAVEL.
1790
COINCIDENCE OF OPERATING AND-RELEASE POINTS (SIMULTANEITY).
TESTING SHALL BE PERFORMED IN ACCORDANCE WITH THE BASE
DOCUMENT, EXCEPT 1790.
1792 COINCIDENCE OF OPERATING AND RELEASE POINTS (SIMULTANEITY).
TESTING SHALL BE PERFORMED IN ACCORDANCE WITH 1792.
53
